Put the battery back into the frame and hold it. The locking mechanism
will align now with the battery. Tighten the screws at 4 to 5 Nm.
25
Check if the battery can smoothly move in and out of the frame when
locking and unlocking.
Check if the secondary lock functions properly so the battery cannot
accidentally drop out of the frame.
If everything works properly, the process is finished.
