4.1 Safety regulations
• Only a local gas utility technician is authorized to carry out gas
installations and connections. The statutory regulations (applied
in Germany VDE, Austria ÖVE, Switzerland SEV, etc.) and connec-
tion conditions performed by the gas utility must be strictly
observed.
• Connection to a power balance system for the installation in a
wall is provided for through a connection point. Adhere to cur-
rent local legal requirements for connection.
• Please note the electrical diagram! Compare the wiring diagram
number on the data plate of the appliance with the one shown
on the electrical diagram.
• Do not bend, crush or damage the cables against sharp corners.
• Lay the cables so as to avoid contact with extremely hot surfaces.
• The cable – which is totally sheathed – must be led inside the
appliance through the cable clamp and cable raceway installed
on the appliance.
• Ventilation system installation can be carried only by expert per-
sonnel.
• If the appliance is to be installed near walls, dividing walls, kitchen
equipment or decorative panelling, these should be in non-inflam-
mable material. If not, all appliances must be coated with thermal-
insulation fireproof material. Make sure that all fire prevention
standards and safety precautions are strictly adhered to.
4.2 Structure, equipment and safety devices
of the unit
Robust steel frame, with 4 height adjustable feet.
18/10 chrome-nickel steel outer panelling.
4.2.1 Cooking zone
• Burner with stabilized flame.
• Gas cocks with safety and adjustable from maximum to minimum.
• Thermoelectric ignition safety.
• Enamelled cast-iron pan supports.
• The bodies of the burners and the venturi tubes are made of cast
iron, while the lid is brass
• 18/10 chrome-nickel steel cooking top.
• Knobs in thermosetting material.
4.2.2 Oven
The cooking chamber is made of stainless steel.
The runners for the pans are made of steel or chromed rod iron.
The pull-out grill is in chromed rod-iron.
The door, with double wall and thermal insulation, is equipped with
an insulated handle and a hinge with balanced spring.
The insulation of the cooking chamber is fibreglass.
Gas version GN 2/1 and MAXI
The tubular burners are in chromed steel and are resistant to ther-
mal and mechanical stress.
Gas is supplied through a safety valve with a thermostat.
The main burner is switched on from a pilot burner with a fixed noz-
zle. It is also equipped with a thermoelectric ignition safety with a
thermocouple connected to the pilot burner. The burner has a piezo
ignition.
The adjustment of the oven temperature, which can be varied
between 160 and 300° C, is made with the thermostat.
The bottom of the oven, in cast iron with reinforced ribs (for GN 2/1)
and steel (for MAXI), is in two pieces.
The smoke collector is in aluminised sheet metal and the protection
grill is in enamelled cast iron.
Gas version GN 1/1 ventilated
The tubular burners are in stainless steel and are resistant to ther-
mal and mechanical stress.
Gas is supplied through a safety valve with a thermostat and a safe-
ty thermocouple.
The ignition of the main burner takes place by means of an AT
transformer.
The adjustment of the oven temperature, which can be varied
between 160 and 300° C, is made with the thermostat.
The bottom of the oven is made of stainless steel.
The smoke collector is in aluminised sheet metal and the protection
grill is in enamelled cast iron.
Electric version GN 2/1
The heating elements are in the top (upper heat) and under the
bottom (lower heat).
Temperature adjustment between 50 and 300° C is made by a ther-
mostat connected to a tri-polar switch.
It is possible to turn on the upper and lower heating elements sepa-
rately or at the same time.
Indicator lights show when voltage is supplied to the appliance (see
Fig. 4A).
The cooking chamber is made of stainless steel.
The upper heating elements are visible (grill), while the lower ones
are covered by a sheet of stainless steel.
Electric version GN 1/1 ventilated
The heating elements are in the top (upper heat), under the bottom
(lower heat), and in the rear around the fan (convection).
The upper heating elements are visible (grill), while the lower ones
are covered by stainless steel panels.
Temperature adjustment between 50 and 300° C is made by a ther-
mostat connected to a switch.
The use of a 9-position commutator makes it possible to light the
heating elements separately or at the same time with ventilation or
in static mode.
The lighting of the heating elements is indicated by 2 indicator
lights (see fig. 4B).
4.2.3 Neutral cabinet
In models K6FFG, K6FFE, a neutral cabinet with a door alongside the
oven is standard.
4.3 Assembly
4.3.1 Installation premises
The appliance should be installed in a well-ventilated room, and if
possible under a range hood (check current regulations).
The appliance can be installed on its own or with other similar
equipment.
If the appliance is to be installed near inflammable walls, a mini-
mum distance of 150 mm around the sides and back should be
allowed.
If this distance cannot be obtained, take proper heat-protection
action such as fitting tiles or thermal radiation protection material
to the walls.
Before connecting the appliance to the gas supply, check on the
data plate that the appliance is suitable and type-tested for the
type of gas available.
If not, see paragraph “Conversion and adjustment”.
