Gigabyte B360M D3P User Manual

USB  Chipset:
- 1 x USB Type-C
™
port on the back panel, with USB 3.1 Gen 2 support
- 1 x USB 3.1 Gen 2 Type-A port (red) on the back panel
- 4 x USB 3.1 Gen 1 ports (2 ports on the back panel, 2 ports available through
the internal USB header)
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through
the internal USB headers)
* The CNVi connector shares bandwidth with the F_USB2 header. When a Wi-Fi
module is populated in the CNVi connector, one of the USB 2.0/1.1 ports routed to
the F_USB2 header becomes unavailable.
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x CPU fan header
 3 x system fan headers
 1 x M.2 Socket 3 connector
 6 x SATA 6Gb/s connectors
 1 x front panel header
 1 x front panel audio header
 1 x S/PDIF Out header
 1 x Thunderbolt
™
add-in card connector
 1 x USB 3.1 Gen 1 header
 2 x USB 2.0/1.1 headers
 1 x serial port headers
 1 x Clear CMOS jumper
Back Panel
Connectors
 1 x PS/2 keyboard/mouse port
 1 x DVI-I port
 2 x DisplayPorts
 1 x USB 3.1 Gen 2 Type-A port (red)
 1 x USB Type-C
™
port, with USB 3.1 Gen 2 support
 2 x USB 3.1 Gen 1 ports
 2 x USB 2.0/1.1 ports
 1 x RJ-45 port
 6 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 Voltage detection
 Temperature detection
 Fan speed detection
 Overheating warning
 Fan fail warning
 Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you
install.
BIOS  1x128Mbitash
 Use of licensed AMI UEFI BIOS
 PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- 7 -

Gigabyte B360M D3P Specifications

General

Manual	Yes
Cables included	SATA
Bundled software	Norton Internet Security, cFosSpeed
Audio chip	Realtek ALC892
Component for	PC
Power source type	ATX
Motherboard chipset	Intel B360 Express
PC health monitoring	FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Motherboard chipset family	Intel
Windows operating systems supported	Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64
Processor socket	LGA 1151 (Socket H4)
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7, Intel Pentium
Maximum number of SMP processors	1
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2666 MHz
Graphics card	HD Graphics
Maximum resolution	4096 x 2304 pixels
Maximum graphics card memory	1024 MB
Number of displays supported	3
Parallel processing technology support	CrossFire
DisplayPort version	1.2
HDMI ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Number of SATA III connectors	6
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	128 Mbit
Desktop Management Interface (DMI) version	2.7

Weight and Dimensions

Depth	230 mm
Width	244 mm
