Gigabyte B760I AORUS PRO DDR4 - 1-2 Motherboard Block Diagram

- 5 -
1-2 Motherboard Block Diagram
LGA1700 CPU
DMI 4.0
4 SATA 6Gb/s
eSPI
Bus
CNVi
SPI
Bus
DDI
DDI
Line Out
MIC
S/PDIF Out
CODEC
iTE
®
Super I/O
4 USB 3.2 Gen 1
Intel
®
B760
1 DisplayPort
1 HDMI
USB 3.2
Gen 1 Hub
4 USB 2.0/1.1
BIOS
PCI Express 4.0 Bus
PCI Express 4.0 Bus
1 M.2 Socket 3
(M2A_CPU)
1 M.2 Socket 3
(M2P_SB)
1 USB 3.2 Gen 2 Type-A
2 USB 3.2 Gen 1
DDR4 3200/3000/2933/2666/2400/2133 MT/s
x16
1 PCI Express x16
x4
x4
LAN
RJ45
PCI Express Bus
x1 x1
Intel
®
2.5GbE LAN
M.2 WIFI
1 USB Type-C
®
,
with USB 3.2 Gen 2 support
1 USB Type-C
®
,
with USB 3.2 Gen 1 support
