- 27 - System Hardware Installation
3-4 Replacing the System FAN Module
CAUTION!
Before you remove or install the system fans follow these steps:
• Disconnect all necessary cable connections. Failure to observe these warnings could result in
personal injury or damage to the equipment.
Rear
Fan5/6
Rear
Fan1/2
Rear
Fan3/4
Rear
Fan11/12
Rear
Fan7/8
Rear
Fan9/10
Follow these instructions to replace the system fan module:
[For all system fan modules]
1. Pull up to remove the fan module by using handle.
2. Reverse the previous steps to install the replacement fan module.
