- 23 -
System Hardware Installation
3-2 Removing and Installing the HGX Tray
Follow these instructions to remove/install the HGX tray:
1. Unlock the latch in the center of front system.
2. Pull the grip handles on the both sides of the system slide the tray to the front of the system at the
same time to remove the tray.
3. Follow steps 1-2 in reverse order to re-install the HGX.
2
3
3
Before you remove or install the HGX tray.
• Make sure the system is not turned on or connected to AC power.
