7ZMM Series Motherboard
3
Feature Summary
Form Factor
y
24.4 cm x 22.2 cm Micro ATX size form factor, 4 layers
PCB.
Motherboard
y
7ZMM series includes 7ZMM, 7ZMM-1
CPU
y
AMD Athlon
TM
/Duron
TM
(K7) Socket A Processor
y
256K/64K L2 cache on die
y
Supports 600MHz ~ 1GHz and above
Chipset Pro Savage KM133, consisting of:
y
VT8365 Memory/AGP/PCI Controller (PAC)[For 7ZMM]
y
VT8364 Memory/AGP/PCI Controller (PAC)[For 7ZMM-1]
y
VT82C686B PCI Super-I/O Integrated Peripheral
Controller (PSIPC)
Clock Generator
y
ICS 9248BF-141
100/102/104/106/108/110/112/133 MHz system bus
speeds
Memory
y
2 168-pin DIMM sockets
y
Supports PC-100/133 and VCM SDRAM
y
Supports up to 1.0GB DRAM
y
Supports only 3.3V SDRAM DIMM
I/O Control
y
VT82C686B
Slots
y
1 AGP slot supports 4X mode & AGP 2.0 compliant
(7ZMM-1 does not have AGP slot)
y
3 PCI slots supports 33MHz & PCI 2.2 compliant
y
1 AMR (Audio Modem Riser) slot
On-Board IDE
y
2 IDE bus master (UDMA 33/ATA 66/ATA100) IDE ports
for up to 4 ATAPI devices
y
Supports PIO mode 3, 4 (UDMA 33/ATA 66/ATA100) IDE
& ATAPI CD-ROM
On-Board
Peripherals
y
1 floppy port supports 2 FDD with 360K, 720K, 1.2M,
1.44M and 2.88M bytes
y
1 parallel port supports Normal/EPP/ECP mode
y
1 serial port (COM A)
y
4 USB ports
Hardware Monitor
y
CPU/System fan revolution detection
y
CPU/Power/System fan control
y
System voltage detection
y
CPU/System temperature detection
To be continued…
