Gigabyte GA-970A-UD3P User Manual

Hardware Installation
- 10 -
 
CPU  AM3+ Socket:
 
- AMD AM3 Phenom
™
II processor/ AMD Athlon
™
II processor

Hyper Transport
Bus
 4800 MT/s
Chipset
 North Bridge: AMD 970
 South Bridge: AMD SB950
Memory  4 x DDR3 DIMM sockets supporting up to 32 GB of system memory
 

the physical memory installed.
 Dual channel memory architecture
 
 

 

Audio  Realtek
®
ALC892 codec
 
 2/4/5.1/7.1-channel
 Support for S/PDIF Out
LAN  Realtek
®

Expansion Slots  
 

 
 3 x PCI Express x1 slots

 2 x PCI slots
Storage Interface  South Bridge:
- 6 x SATA 6Gb/s connectors
- Support for RAID 0, RAID 1, RAID 5, RAID 10, and JBOD
USB  South Bridge:
 

 
®

 

Internal
Connectors
 
 
 6 x SATA 6Gb/s connectors
 1 x CPU fan header
 2 x system fan headers
 1 x power fan header
 1 x front panel header

Gigabyte GA-970A-UD3P Specifications

General

Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2000 MHz
System bus rate	4.8 GT/s
Processor socket	Socket AM3+
Processor manufacturer	AMD
Compatible processor series	AMD Phenom FX, AMD Phenom II Dual-Core Mobile, AMD Phenom II Quad-Core Mobile, AMD Phenom II Triple-Core Mobile, AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6, AMD Phenom II X8
USB 2.0 connectors	3
S/PDIF out connector	Yes
Number of SATA connectors	-
Number of SATA III connectors	6
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	8
Audio chip	VIA VT2021
Cooling type	Passive
Component for	PC
Motherboard chipset	AMD 970
PC health monitoring	CPU, FAN, Power supply, Temperature
Audio output channels	7.1 channels
Motherboard form factor	ATX
Motherboard southbridge	AMD SB950
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
RAID levels	0, 1, 5, 10, JBOD
Supported storage drive interfaces	SATA III
Parallel processing technology support	2-Way CrossFireX
PCI Express slots quantity	5
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	244 mm
Width	305 mm
