- 5 -
GA-H61M-S1 Motherboard Layout
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
Box Contents
GA-H61M-S1 motherboard
5
Motherboard driver disk
5
Two SATA cables
5
User's Manual
5
I/O Shield
5
KB_MS
CPU_FAN
LGA1155
ATX
GA-H61M-S1
F_AUDIO
AUDIO
DDR3_1
DDR3_2
BAT
F_PANEL
ATX_12V
Intel
®
H61
SATA2
R_USB
CODEC
CLR_CMOS
M_BIOS
VGA
USB_LAN
PCIEX16
PCIEX1_1
F_USB1
F_USB2
iTE
IT8728
Realtek
RTL8111F
SYS_FAN
1 0
3 2
PCIEX1_2
