- 5 -
GA-B75M-D2P Motherboard Block Diagram
PS/2 KB/Mouse
LGA1155
CPU
Intel
®
B75
PCIe CLK
(100 MHz)
CPU CLK+/- (100 MHz)
1 PCI Express x16
BIOS
COM
LPT
6 USB 2.0/1.1
4 USB 3.0/2.0
LPC
Bus
DDR3 1600/1333/1066 MHz
LAN
RJ45
PCI Express Bus
PCI Express Bus
PCIe CLK
(100 MHz)
Realtek
®
GbE LAN
1 PCI Express x1
5 SATA 3Gb/s
D-Sub
DMI 2.0
FDI
x16
Dual Channel Memory
x1 x1
iTE
®
Super I/O
For detailed product information/limitation(s), refer to "1-2 Product Specications."
Line Out (Front Speaker Out)
MIC (Center/Subwoofer
Speaker Out)
Line In (Rear Speaker Out)
CODEC
PCI CLK
(33 MHz)
1 PCI
PCI Bus
1 SATA 6Gb/s
