Gigabyte GA-B75M-D3V - Motherboard Layout

- 5 -
GA-B75M-D3V Motherboard Layout
KB_MS_USB
CPU_FAN
SYS_FAN
LGA1155
ATX
GA-B75M-D3V
F_AUDIO
AUDIO
B_BIOS
DDR3_1 DDR3_2
BAT
ATX_12V
Intel
®
B75
SATA2
SATA2
R_USB30
CODEC
CLR_CMOS
F_USB30
M_BIOS
VGADVI
LPT
USB_LAN
PCIEX16
PCIEX1_1
PCIEX1_2
PCI
iTE Super I/O
The box contents above are for reference only and the actual items shall depend on the product package you obtain.
Atheros
GbE LAN
F_USB2 F_USB1 F_PANELCOM
2
4 3
SATA2 1 SATA3 0
5
Box Contents
GA-B75M-D3V motherboard
5
Motherboard driver disk
5
Two SATA 6Gb/s cables
5
User's Manual
5
I/O Shield
5
