Gigabyte GA-F2A55M-S1 User Manual

- 8 -
Internal
Connectors
 1 x S/PDIF Out header
 2 x USB 2.0/1.1 headers
 1 x Clear CMOS jumper
Back Panel
Connectors
 1 x PS/2 keyboard port
 1 x PS/2 mouse port
 1 x D-Sub port
 4 x USB 2.0/1.1 ports
 1 x RJ-45 port
 3 x audio jacks (Line In/Line Out/Microphone)
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 System voltage detection
 APU/System temperature detection
 APU/System fan speed detection
 APU overheating warning
 APU/System fan fail warning
 APU/System fan speed control
* Whether the fan speed control function is supported will depend on the cooler you
install.
BIOS  1 x 32 Mbit ash
 Use of licensed AMI EFI BIOS
 PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features  Support for @BIOS
 Support for Q-Flash
 Support for Xpress Install
 Support for EasyTune
* Available functions in EasyTune may differ by motherboard model.
 Support for Smart Recovery2
 Support for ON/OFF Charge
Bundled
Software
 Norton
®
Internet Security (OEM version)
Operating
System
 Support for Windows 8.1/8/7/Vista/XP
* Support for Windows 8.1/8/7 only when an AMD FM2 Richland APU is installed.
* If you plan to install Windows 8.1, please download the latest drivers from GIGABYTE's
website.
Form Factor  Micro ATX Form Factor; 22.5cm x 17.4cm
* GIGABYTE reserves the right to make any changes to the product specications and product-related information without
prior notice.
* Please visit the Support & Downloads\Utility page on GIGABYTE's website to check the supported operating system(s)
for the software listed in the "Unique Features" and "Bundled Software" columns.

Gigabyte GA-F2A55M-S1 Specifications

General

Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2400 MHz
Processor socket	Socket FM2
Processor manufacturer	AMD
Compatible processor series	AMD A
S/PDIF out connector	Yes
Number of SATA connectors	4
Number of EATX power connectors	1
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	-
Headphone outputs	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Component for	PC
Power source type	ATX
Motherboard chipset	AMD A55
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA II
BIOS type	EFI AMI
ACPI version	1.0b
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	174 mm
Width	225 mm
