Gigabyte GA-F2A55M-S1 User Manual

- 7 -
1-2 ProductSpecications
APU  FM2 Socket:
- AMD A series processors
- AMD Athlon
™
series processors
(Go to GIGABYTE's website for the latest CPU support list.)
Chipset  AMD A55
Memory  2 x 1.5V DDR3 DIMM sockets supporting up to 64 GB of system memory
* Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than the size of
the physical memory installed.
* The maximum 64 GB of system memory can be supported using 16 GB (or above)
memory modules. GIGABYTE will update the memory support list on the ofcial
website when the memory modules are available on the market.
 Dual channel memory architecture
 Support for DDR3 1866/1600/1333/1066 MHz memory modules
 Support for AMD Memory Prole (AMP)/Extreme Memory Prole (XMP) memory
modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
 APU with integrated AMD Radeon
™
HD 8000/7000 series graphics:
- 1 x D-Sub port, supporting a maximum resolution of 1920x1200
- Maximum shared memory of 2 GB
Audio  Realtek
®
ALC887 codec
 High Denition Audio
 2/4/5.1/7.1-channel
* To congure 7.1-channel audio, you have to use an HD front panel audio module
and enable the multi-channel audio feature through the audio driver.
 Support for S/PDIF Out
LAN  Realtek
®
GbE LAN chip (10/100/1000 Mbit)
Expansion Slots  1 x PCI Express x16 slot, running at x16
 1 x PCI Express x1 slot
(The PCI Express slots conform to PCI Express 2.0 standard.)
 1 x PCI slot
Multi-Graphics
Technology
 Support for AMD Dual Graphics technology
* Only A series APUs support AMD Dual Graphics.
Storage Interface  Chipset:
- 4 x SATA 3Gb/s connectors
- Support for RAID 0, RAID 1, RAID 10, and JBOD
USB  Chipset:
- 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through
the internal USB headers)
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 4-pin ATX 12V power connector
 4 x SATA 3Gb/s connectors
 1 x CPU fan header
 1 x system fan header
 1 x front panel header
 1 x front panel audio header

Gigabyte GA-F2A55M-S1 Specifications

General

Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2400 MHz
Processor socket	Socket FM2
Processor manufacturer	AMD
Compatible processor series	AMD A
S/PDIF out connector	Yes
Number of SATA connectors	4
Number of EATX power connectors	1
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	-
Headphone outputs	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Component for	PC
Power source type	ATX
Motherboard chipset	AMD A55
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA II
BIOS type	EFI AMI
ACPI version	1.0b
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	174 mm
Width	225 mm
