Gigabyte GA-F2A78M-DASHV User Manual

- 4 -
GA-F2A78M-DASHV Motherboard Layout
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
(Note) Whether this feature is supported depends on the product being received.
Box Contents
5 GA-F2A78M-DASHV motherboard
5 Motherboard driver disk 5 Four SATA cables
5 User's Manual 5 I/O Shield
5 Quick Installation Guide
KB_MS_USB
CPU_FANSYS_FAN1
FM2+
ATX
GA-F2A78M-DASHV
F_AUDIO
AUDIO
DDR3_1 DDR3_3 DDR3_2 DDR3_4
BAT
ATX_12V
SATA3
R_USB30
USB30_LAN
DP_HDMI
CODEC
M_BIOS
VGA
DVI
PCIEX16
LPT
PCIEX4
PCIEX1
TPM IC
(Note)
PCI
F_USB2 F_PANELF_USB30_2
F_USB30_1
F_USB1COMBCOMA
SYS_FAN2
SPDIF_O
CLR_CMOS
Realtek
®
GbE LAN
VIA
®
VL805
AMD A78
0 2 4 1 3 5
iTE
®
Super I/O
