Gigabyte GA-F2A88X-UP4 User Manual

- 11 -
Hardware Installation
Expansion Slots  1xPCIExpressx16slot,runningatx4(PCIEX4)
* ThePCIEX1_3slotsharesbandwidthwiththePCIEX4slot.WhenthePCIEX1_3
slot is populated, the PCIEX4 slot will operate at up to x1 mode.
 3 x PCI Express x1 slots
 (ThePCIEX4andPCIExpressx1slotsconformtoPCIExpress2.0standard.)
 1 x PCI slot
Multi-Graphics
Technology
 Support for AMD CrossFire
™
technology(PCIEX16andPCIEX8)
 Support for AMD Dual Graphics technology
* OnlyAseriesAPUssupportAMDDualGraphics.
Storage Interface  Chipset:
- 7xSATA6Gb/sconnectors(SATA30~6)
- 1 x eSATA connector on the back panel
* Actualtransferrateisdependentonthedevicebeingconnected.
- Support for RAID 0, RAID 1, RAID 5, RAID 10, and JBOD
USB  Chipset:
- 4USB3.0/2.0ports(availablethroughtheinternalUSBheaders)
- 10USB2.0/1.1ports(2portsonthebackpanel,8portsavailablethrough
theinternalUSBheaders)
 VIA
®
VL805 chip:
- 4 USB 3.0/2.0 ports on the back panel
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 7 x SATA 6Gb/s connectors
 1 x APU fan header
 3 x system fan headers
 1 x front panel header
 1 x front panel audio header
 1 x S/PDIF Out header
 2 x USB 3.0/2.0 headers
 4 x USB 2.0/1.1 headers
 1 x serial port header
 1 x Clear CMOS jumper
 1 x power button
 1 x reset button
 1 x Clear CMOS button
Back Panel
Connectors
 1 x PS/2 keyboard/mouse port
 1 x D-Sub port
 1 x DVI-D port
 1 x optical S/PDIF Out connector
 1 x HDMI port
 1 x DisplayPort
 4 x USB 3.0/2.0 ports
 2 x USB 2.0/1.1 ports
 1 x eSATA connector
 1 x RJ-45 port
 6xaudiojacks(Center/SubwooferSpeakerOut,RearSpeakerOut,SideSpeaker
Out,LineIn,LineOut,MicIn)
