- 7 -
GA-F2A88X-UP4 Motherboard Layout
KB_MS_USB3
CPU_FAN
SYS_FAN1
Socket FM2+
ATX
F_USB30_1
AUDIO
DDR3_4
DDR3_2
DDR3_3
DDR3_1
BAT
ATX_12V
AMD A88X
CODEC
CLR_CMOS
VIA
®
VL805
M_BIOS
DB_PORT
(Note)
B_BIOS
DVI_VGA
USB30_LAN
Realtek
®
GbELAN
PCIEX16
PCIEX1_2
PCIEX4
PCI
PCIEX1_3
SYS_FAN3
RST_SW
PW_SW
CMOS_SW
iTE
®
Super I/O
GA-F2A88X-UP4
DP_HDMI_SPDIF
USB_ESATA
F_PANEL
SYS_FAN2
F_USB1 F_USB30_2F_USB3 F_USB2F_USB4F_AUDIO
SPDIF_O
COM
PCIEX1_1
PCIEX8
SATA3
SATA3
SATA3
SATA3
2
1
0
4
3
6
5
(Note) Fordebugcodeinformation,pleaserefertoChapter6.
