Gigabyte GA-H310MSTX-HD3-CM - Internal Connectors

1-7 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) CPU_FAN
2) SYS_FAN
3) SATA3 0/1
4) SATA_PWR
5) M2A
6)
BATTERY
7)
BAT
8) COMA/COMB
9) 2W_SPKR
10) SPEAKER
11) F_USB
12) F_PANEL
13) CI
14) CLR_CMOS
15) MIC_IN
16) TYPEC
17) USB30
18) H P_MIC
7
3
6
15
16
17
18
10 2 811 13 12 9
14
5
4
1
- 11 -
