Gigabyte GA-H310MSTX-HD3-CM User Manual

- 4 -
GA-H310MSTX-HD3-CM/GA-H310MSTX-HD3-T20-ZK
Motherboard Layout
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
(Note 1) This chip is on the back of the motherboard.
(Note 2) Only for GA-H310MSTX-HD3-T20-ZK.
DC_PWR
CPU_FAN
LGA1151
BATTERY
HP_MIC
Intel
®
H310
SATA3
0
1
2W_SPKR
CODEC
iTE
®
Super
I/O
(Note 1)
F_USB
SPEAKER
CLR_CMOS
USB30_LAN
HDMI 20
Intel
®
GbE LAN
DP
VGA
DDR4_1 DDR4_2
M_BIOS
SYS_FAN
SATA_PWR
USB30
TYPEC
MIC_IN
M2_WIFI
M2A
COMB COMA F_PANEL
CI
BAT
30
80
GA-H310MSTX-HD3-CM
GA-H310MSTX-HD3-T20-ZK
TPM IC
(Note 1)(Note 2)
Box Contents
5 GA-H310MSTX-HD3-CM or GA-H310MSTX-HD3-T20-ZK motherboard
5 Motherboard driver disc 5 SATA power cable
5 User's Manual 5 I/O Shield
5 SATA cable 5 COM port cable
5 Power adapter j 5 Power cord j
j Only for GA-H310MSTX-HD3-T20-ZK.
