16) USB30 (USB 3.0/2.0 Connector)
TheUSBportmakesiteasiertosavedata,ashtheBIOSorinstallsoftwareinopenbenchtestingplatforms
forsimplypretestingthePCbeforenalcomponentinstallationinsideacasescenarioswhereaccessing
the rear panel IO can be an inconvenience.
F_USB3 (Front Panel)
HP_MIC/MIC
TYPEC
17) TYPEC (USB Type-C
™
Port, with USB 3.1 Gen 1 support)
Thereversible USBport supportstheUSB 3.1Gen 1specication andis compatibleto theUSB2.0
specication.UsethisportforUSBdevices.
F_USB3 (Front Panel)
HP_MIC/MIC
TYPEC
18) HP_MIC (Headphone and Microphone Combo Jack)
This jack is for connecting a headphone or microphone. You can connect a microphone, headphone or
speaker to this jack.
F_USB3 (Front Panel)
HP_MIC/MIC
TYPEC
