Gigabyte GA-M52L-S3P User Manual

- 41 - BIOS Setup
2-6 Integrated Peripherals
CMOS Setup Utility-Copyright (C) 1984-2008 Award Software
Integrated Peripherals
On-Chip IDE Channel [Enabled]
NV SATA Controller [Enabled]
IDE Prefetch Mode [Enabled]
USB Memory Type [SHADOW]
 Serial-ATA RAID Config [Press Enter]
Onboard Audio Function [Auto]
On-Chip MAC Lan [Auto]
Onboard LAN Boot ROM [Disabled]
Onboard Serial Port 1 [3F8/IRQ4]
Onboard Parallel Port [378/IRQ7]
Parallel Port Mode [SPP]
x ECP Mode Use DMA 3
On-Chip USB [V1.1+V2.0]
USB Keyboard Support [Disabled]
USB Mouse Support [Disabled]
Legacy USB storage detect [Enabled]
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
On-Chip IDE Channel
Enables or disables the integrated IDE controller. (Default: Enabled)
NV SATA Controller
Enables or disables the integrated SATA 3Gb/s controller. (Default: Enabled)
IDE Prefetch Mode
Enables or disbales prefetch mode for the integrated IDE controller. Enabled activates the IDE
prefetch buffer to enhance hard drive performance. (Default: Enabled)
USB Memory Type
Specifies the type of memory allocated for USB devices. Options are: SHADOW (default), Base
Memory (640K).
Serial-ATA RAID Config
CMOS Setup Utility-Copyright (C) 1984-2008 Award Software
Serial-ATA RAID Config
Item Help
Menu Level
NV SATA RAID function [Disabled]
x NV SATA 1 Primary RAID Enabled
x NV SATA 1 Secondary RAID Enabled
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

Gigabyte GA-M52L-S3P Specifications

General

Memory voltage	1.8 V
Number of memory slots	4
Maximum internal memory	16 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
USB 2.0 connectors	8
Power fan connector	Yes
Number of SATA connectors	2
Headphone outputs	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC883
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Microsoft Windows Vista/XP
BIOS type	AWARD
Trial software	Norton Internet Security
LAN controller	Realtek RTL8201CL
Networking features	10/100 Mbit
