GA-M52L-S3P Motherboard Layout
KB_MS
LPT
ATX
Socket AM2
COMA
ATX_12V
F_PANEL
PWR_LED
CLR_CMOS
PCI1
PCI2
IT8718
BATTERY
B_BIOS
CI
SPDIF_I
CODEC
FDD
CD_IN
GA-M52L-S3P
IDE
SYS_FAN
CPU_FAN
F_AUDIO
PCIEX16_1
DDR2_1
DDR2_2
AUDIO
Realtek
8201CL
PCIEX1_1
R_USB
DDR2_3
DDR2_4
PCIEX1_2
PCI3
PCI4
NVIDIA
®
nForce 520LE
SATA2_1
F_USB2 F_USB1
SATA2_0
USB
LAN
COAXIAL
SPDIF_O
