Gigabyte GA-M61PME-S2P User Manual

Hardware Installation- 11 -
Internal Connectors  1 x CD In connector
 1 x S/PDIF In/Out header
 2 x USB 2.0/1.1 headers
 1 x chassis intrusion header
 1 x power LED header
Back Panel  1 x PS/2 keyboard port
Connectors  1 x PS/2 mouse port
 1 x parallel port
 1 x serial port
 1 x D-Sub port
 4 x USB 2.0/1.1 ports
 1 x RJ-45 port
 3 x audio jacks (Line In/Line Out/Microphone)
I/O Controller  iTE IT8718 chip
Hardware Monitor  System voltage detection
 CPU/System temperature detection
 CPU/System fan speed detection
 CPU/System overheating warning
 CPU/System fan fail warning
 CPU fan speed control
(Note 3)
BIOS  2 x 8 Mbit flash
 Use of licensed AWARD BIOS
 Support for DualBIOS
TM
 PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features  Support for @BIOS
 Support for Q-Flash
 Support for Virtual Dual BIOS
 Support for Download Center
 Support for Xpress Install
 Support for Xpress Recovery2
 Support for EasyTune
(Note 4)
Bundled Software  Norton Internet Security (OEM version)
Operating System  Support for Microsoft
®
Windows
®
Vista/XP
Form Factor  Micro ATX Form Factor; 24.4cm x 22.5cm
(Note 1) Due to Windows Vista/XP 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than 4 GB.
(Note 2) A 5.1/7.1 surround cable (optional) needs to be installed if you wish to enable 7.1-channel
audio output.
(Note 3) Whether the CPU fan speed control function is supported will depend on the CPU cooler you
install.
(Note 4) Available functions in EasyTune may differ by motherboard model.

Gigabyte GA-M61PME-S2P Specifications

General

Memory voltage	1.8 V
Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
USB 2.0 connectors	4
Power fan connector	Yes
Number of Parallel ATA connectors	1
Special features	@BIOS Download Center Q-Flash Virtual Dual BIOS EasyTune(Note 4) Xpress Install Xpress Recovery2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC883
Power source type	ATX
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Microsoft Windows Vista/XP
Bundled software	Norton Internet Security (OEM version)
LAN controller	Realtek RTL8201CL
Networking features	10/100 Mbit
Graphics card	GeForce 6100

Weight and Dimensions

Depth	225 mm
Width	244 mm
