Gigabyte GA-N650SLI-DS4L User Manual

GA-N650SLI-DS4L Motherboard - 24 -
1-8 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the
power cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable
has been securely attached to the connector on the motherboard.
11) BAT
12) F_PANEL
13) F_AUDIO
14) CD_IN
15) SPDIF_O
16) SPDIF_IN
17) F_USB1/F_USB2
18) CLR_CMOS
19) CI1
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN
5) PWR_FAN
6) NB_FAN
7) FDD
8) IDE1
9) SATAII0/1/2/3
10) PWR_LED
2
1
17
8
13
16 19
3
5
12
6
7 1015
14
4 11
9
18
