GA-N650SLI-DS4L Motherboard - 52 -
2-9 MB Intelligent Tweaker(M.I.T.)
CMOS Setup Utility-Copyright (C) 1984-2007 Award Software
MB Intelligent Tweaker(M.I.T.)
` System Clock Setting [Press Enter]
CPU Clock Ratio
(Note)
[16X]
******** System Voltage Optimized ********
System Voltage Control [Manual]
DDR2 Voltage Control [Normal]
NB/HT-Link Voltage [Normal]
FSB Voltage [Normal]
South Bridge Voltage [Normal]
VCC12_DL Voltage [Normal]
CPU Voltage Control [Normal]
Normal CPU Vcore 1.40000V
KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level`
• Incorrectly doing overclock/overvoltage may result in damage to CPU, chipset, or memory
and reduce the useful life of these components. This page is for advanced users only and
we recommend you not to alter the default settings to prevent system instability or other
unexpected results. (Inadequately altering the settings may result in system's failure to
boot. If this occurs, clear the CMOS values and reset the board to default values.)
• When the System Voltage Optimized item blinks in red, it is recommended that you set
the System Voltage Control item to Auto to optimize the system voltage settings.
System Clock Setting
CMOS Setup Utility-Copyright (C) 1984-2007 Award Software
System Clock Setting
Item Help
Menu Level`
FSB-Memory Clock Mode [Auto]
x FSB-Memory Ratio Auto
x CPU Host Frequency (Mhz) Auto 133.3
Actual CPU Clock (Mhz) 133.3
x Memory Frequency (Mhz) Auto 800.0
Actual Memory Clock (Mhz) 800.0
PCIe Bus, Slot 1, MHz [100]
KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
(Note) This item is present only if you install a CPU that supports this feature.
