Gigabyte GA-X99-UD3P User Manual

- 11 -
Hardware Installation
Storage Interface  (M2_10G,SATAExpress,andSATA34/5connectorscanonlybeusedoneata
time. The SATA3 4/5 connectors will become unavailable when an M.2 SSD is
installedintheM2_10Gconnector.)
 Chipset:
- 4xSATA6Gb/sconnectors(sSATA30~3),supportingIDEandAHCImodes
only
(AnoperatingsysteminstalledontheSATA30~5portscannotbeusedonthe
sSATA30~3ports.)
USB  Chipset:
 - 4xUSB3.0/2.0ports(2portsonthebackpanel,2portsavailablethrough
theinternalUSBheader)
 - 8xUSB2.0/1.1ports(4portsonthebackpanel,4portsavailablethrough
theinternalUSBheaders)
 Chipset + Renesas
®
uPD720210 USB 3.0 Hub:
- 4 x USB 3.0/2.0 ports on the back panel
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x PCIe power connector
 1 x M.2 Socket 3 connector
 1 x SATA Express connector
 10 x SATA 6Gb/s connectors
 1 x CPU fan header
 1xwatercoolingfanheader(CPU_OPT)
 3 x system fan headers
 1 x front panel header
 1 x front panel audio header
 1 x USB 3.0/2.0 header
 2 x USB 2.0/1.1 headers
 1xTrustedPlatformModule(TPM)header
 1 x Thunderbolt
™
add-in card connector
 1 x Clear CMOS jumper
 1 x CPU mode switch
Back Panel
Connectors
 1 x PS/2 keyboard port
 1 x PS/2 mouse port
 6 x USB 3.0/2.0 ports
 4 x USB 2.0/1.1 ports
 1 x RJ-45 port
 1 x optical S/PDIF Out connector
 5 xaudio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, LineIn,
LineOut,MicIn)
 2 x Wi-Fi antenna connector holes
