Hardware Installation
1-8 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V_2X4
2) ATX
3) ATX4P
4) CPU_FAN
5) SYS_FAN1/2/3
6) CPU_OPT
7) SATA_EXPRESS
8) SATA3 0/1/2/3/4/5
9) sSATA3 0/1/2/3
10) M2_10G
11) M2_WIFI
12) F_PANEL
13) F_ AUDIO
14)
SPDIF_O
15) F_USB30
16) F_USB1/F_USB2
17) TPM
18) THB_C
19) BAT
20) CLR_CMOS
21) CPU Mode Switch
2
12
7
16 101713 5
1
6
9
3
4
19
15
14
8
20
18
5
5
11
8
21
