Gigabyte GA-X99-UD5 WIFI User Manual

- 11 -
Hardware Installation
Storage Interface  Chipset:
- 4xSATA6Gb/sconnectors(sSATA30~3),supportingIDEandAHCImodes
only
(AnoperatingsysteminstalledontheSATA30~5portscannotbeusedonthe
sSATA30~3ports.)
USB  Chipset:
 - 4xUSB3.0/2.0ports(2portsonthebackpanel,2portsavailablethrough
theinternalUSBheader)
 - 8xUSB2.0/1.1ports(4portsonthebackpanel,4portsavailablethrough
theinternalUSBheaders)
 Chipset + Renesas
®
uPD720210 USB 3.0 Hub:
- 4 x USB 3.0/2.0 ports on the back panel
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x PCIe power connector
 1 x I/O shield audio LED power connector
 1 x heatsink LED power connector
 1 x M.2 Socket 3 connector
 1 x SATA Express connector
 10 x SATA 6Gb/s connectors
 1 x CPU fan header
 1xwatercoolingfanheader(CPU_OPT)
 3 x system fan headers
 1 x front panel header
 1 x front panel audio header
 1 x USB 3.0/2.0 header
 2 x USB 2.0/1.1 headers
 1xTrustedPlatformModule(TPM)header
 1 x Thunderbolt add-in card connector
 1 x Clear CMOS jumper
Back Panel
Connectors
 1 x PS/2 keyboard port
 1 x PS/2 mouse port
 6 x USB 3.0/2.0 ports
 4 x USB 2.0/1.1 ports
 1 x RJ-45 port
 1 x optical S/PDIF Out connector
 5x audio jacks(Center/Subwoofer Speaker Out, Rear Speaker Out, Line In,
LineOut,MicIn)
 2 x Wi-Fi antenna connector holes
I/O Controller  iTE
®
I/O Controller Chip

Gigabyte GA-X99-UD5 WIFI Specifications

General

Non-ECC	Yes
Memory channels	Quad-channel
Memory slots type	DIMM
Number of memory slots	8
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2666, 2800, 3000 MHz
Processor socket	LGA 2011 (Socket R)
Processor manufacturer	Intel
Compatible processor series	Intel Core i7, Intel Core i7 Extreme Edition
USB 2.0 connectors	4
Number of SATA connectors	10
Number of Parallel ATA connectors	-
USB 3.2 Gen 1 (3.1 Gen 1) connectors	6
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA, SATA II, SATA III
PS/2 ports quantity	1
eSATA ports quantity	0
USB 2.0 ports quantity	2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® X99
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	Extended ATX
Parallel processing technology support	2-Way CrossFireX, 2-Way SLI, 3-Way CrossFireX, 3-Way SLI, 4-Way CrossFireX, 4-Way SLI
PCI Express x1 slots	3
BIOS type	UEFI
ACPI version	5.0

Weight and Dimensions

Depth	259 mm
Width	305 mm
