1-7 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
3
14
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN
5) BAT
6) SATA EXPRESS
7) SATA3 0/1/2/3/4/5
8) M.2
9) F_PANEL
10) F_AUDIO
11) SPEAKER
12) SPDIF_O
13) F_USB30
14) F_USB
15) CLR_CMOS
16) CI
1
2
4
9
7
6
15
7
13
10
5
11
16
12
8
- 13 -
