Gigabyte GA-Z170N-WIFI User Manual

1-2 ProductSpecications
CPU  Support for Intel
®
Core
™
i7 processors/Intel
®
Core
™
i5 processors/
Intel
®
Core
™
i3 processors/Intel
®
Pentium
®
processors/
Intel
®
Celeron
®
processors in the LGA1151 package
(Go to GIGABYTE's website for the latest CPU support list.)
 L3 cache varies with CPU
Chipset  Intel
®
Z170M/H170N Express Chipset
Memory

2 x DDR4 DIMM sockets supporting up to 32 GB of system memory
* Due to a Windows 32-bit operating system limitation, when more than 4 GB of
physical memory is installed, the actual memory size displayed will be less than the
size of the physical memory installed.

Dual channel memory architecture

Support for DDR4 2133 MHz memory modules

Support for ECC UDIMM 1Rx8/2Rx8 memory modules (operate in non-ECC
mode)

Support for non-ECC UDIMM 1Rx8/2Rx8/1Rx16 memory modules

Support for Extreme Memory Prole (XMP) memory modules
M
(Go to GIGABYTE's website for the latest supported memory speeds and
memory modules.)
Onboard
Graphics
 Integrated Graphics Processor-Intel
®
HD Graphics support
- 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
* The DVI-D port does not support D-Sub connection by adapter.
- 2 x HDMI ports, supporting a maximum resolution of 4096x2160@24 Hz
* Support for HDMI 1.4 version.
 Support for up to 3 displays at the same time
 Maximum shared memory of 512 MB
Audio  Realtek
®
ALC1150 codec
 High Denition Audio
 2/4/5.1/7.1-channel
 Support for S/PDIF Out
LAN  2 x Intel
®
GbE LAN chips (10/100/1000 Mbit)
Wireless
Communication
Module
 Wi-Fi 802.11 a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band
 BLUETOOTH 4.2, 4.1, BLE, 4.0, 3.0, 2.1+EDR
 Support for 11ac wireless standard and up to 867 Mbps data rate
* Actual data rate may vary depending on environment and equipment.
Expansion Slots  1 x PCI Express x16 slot, running at x16
(The PCIEX16 slot conforms to PCI Express 3.0 standard.)
 1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI)
Storage Interface  Chipset:
- 1 x M.2 Socket 3 connector on the back of the motherboard
- 2 x SATA Express connectors
- 6 x SATA 6Gb/s connectors
M Only for GA-Z170N-WIFI.
N Only for GA-H170N-WIFI.
- 7 -

Gigabyte GA-Z170N-WIFI Specifications

General

Brand	Gigabyte
Model	GA-Z170N-WIFI
Category	Motherboard
Language	English
