Gigabyte M32Q User Manual

LCD Monitor User's Manual
-
24
-
USING THE DEVICE
Turning the Power On/O
Make sure the power switch next to the AC power input jack is switched to ON.
Power On
1. Connect one end of the power cable to the AC IN jack at the rear of the monitor.
2. Connect other end of the the power cable to a power outlet.
3. Press the Control button to turn on the monitor. The Power LED will light in
white, indicating the monitor is ready to use.
Power O
Press the Control button for 2 seconds to turn o the monitor.
Note: When the Main menu appears on the screen, you can also turn o the monitor by
moving the Control button down ( ). Refer to page 28.

Gigabyte M32Q Specifications

General

Package depth	196 mm
Package width	958 mm
Package height	554 mm
Package weight	13600 g
Swiveling	Yes
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	120 W
Power consumption (off)	0.3 W
Power consumption (typical)	- W
Power consumption (PowerSave)	0.5 W
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
USB upstream port type	USB Type-B
Number of upstream ports	1
USB Type-A downstream ports quantity	3
Panel type	SS-IPS
Color depth	8 bit
Color gamut	94 %
Pixel pitch	0.273 x 0.273 mm
Screen shape	Flat
Response time	0.8 ms
Display diagonal	31.5 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	170 Hz
Viewable size, vertical	392.688 mm
sRGB coverage (typical)	120 %
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	698.112 mm
Display brightness (typical)	350 cd/m²
Cables included	AC, DisplayPort, HDMI, USB
Feet color	Black
Market positioning	Gaming
RMS rated power	6 W
Operating temperature (T-T)	0 - 40 °C
AMD FreeSync type	FreeSync Premium
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	244.3 mm
Width (with stand)	715.8 mm
Height (with stand)	585.3 mm
Weight (with stand)	10200 g
Depth (without stand)	68.2 mm
Height (without stand)	423.8 mm
Weight (without stand)	7100 g
