Gigabyte M32UC User Manual

- 16 -
USING THE DEVICE
Turning the Power On/O
Power On
1. Connect the power cable to the power adapter.
2. Connect the power adapter to the DC IN jack at the rear of the
monitor.
3. Connect the power cable to a power outlet.
4. Press the Control button to turn on the monitor. The Power LED will
light in white, indicating the monitor is ready to use.
Note: If no signal, the monitor will show No Signal notication for a while.
Then, the monitor will go to power saving mode and the Power LED lights
white and starts blinking with a period of one second.
Power O
Press the Control button for 2 seconds to turn o the monitor.
Note: When the Main menu appears on the screen, you can also turn o the
monitor by moving the Control button down ( ). Refer to page 20.

Gigabyte M32UC Specifications

General

Panel type	VA
Color depth	8 bit
Color gamut	93 %
Display diagonal	31.5 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	160 Hz
sRGB coverage (typical)	123 %
Contrast ratio (typical)	3000:1
Display number of colors	-
Display brightness (peak)	350 cd/m²
HDMI	Yes
DisplayPort version	1.4
USB Type-A downstream ports quantity	3
Tilt angle range	-5 - 20 °
Height adjustment	100 mm
Panel mounting interface	100 x 100 mm
RMS rated power	3 W
Input current	4.74 A
Energy efficiency scale	A to G
Power consumption (off)	0.5 W
Power consumption (standby)	- W
Power consumption (typical)	47 W
Package depth	198 mm
Package width	925 mm
Package height	570 mm
Package weight	11980 g
Cables included	HDMI, USB
Product color	Black
Market positioning	Gaming

Weight and Dimensions

Depth (with stand)	100.5 mm
Width (with stand)	710.5 mm
Height (with stand)	423.3 mm
Weight (with stand)	7800 g
Weight (without stand)	5500 g
