Gigabyte M32UC User Manual

- 19 -
• Move the Control button down ( ) to enter the Picture Mode
menu.
Move the Control button
up/down ( ) to select the
desired option and press the
Control button to conrm.
• Move the Control button left ( ) to enter the Volume menu.
Move the Control button
up/down ( ) to adjust
the headphone volume
level and press the Control
button to conrm.
• Move the Control button right ( ) enter the Input menu. Refer to
the “Selecting the Input Source” section.
Note: To close the menu, move the Control button left ( ).
Picture Mode
Standard
FPS
RTS/RPG
Movie
Reader
sRGB
Select Exit
Adjust Exit
Volume
50

Gigabyte M32UC Specifications

General

Panel type	VA
Color depth	8 bit
Color gamut	93 %
Display diagonal	31.5 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	160 Hz
sRGB coverage (typical)	123 %
Contrast ratio (typical)	3000:1
Display number of colors	-
Display brightness (peak)	350 cd/m²
HDMI	Yes
DisplayPort version	1.4
USB Type-A downstream ports quantity	3
Tilt angle range	-5 - 20 °
Height adjustment	100 mm
Panel mounting interface	100 x 100 mm
RMS rated power	3 W
Input current	4.74 A
Energy efficiency scale	A to G
Power consumption (off)	0.5 W
Power consumption (standby)	- W
Power consumption (typical)	47 W
Package depth	198 mm
Package width	925 mm
Package height	570 mm
Package weight	11980 g
Cables included	HDMI, USB
Product color	Black
Market positioning	Gaming

Weight and Dimensions

Depth (with stand)	100.5 mm
Width (with stand)	710.5 mm
Height (with stand)	423.3 mm
Weight (with stand)	7800 g
Weight (without stand)	5500 g
