Gigabyte MS33-AR1 User Manual

- 6 -
Item Code Description
1 LED_BMC BMC Firmware Readiness LED
2 SPI_TPM TPM Connector
3 SW_ID ID Button with LED
4 USB3_MLAN Server Management LAN Port (Top)/USB 3.0 Ports (Bottom)
5 LAN1 10GbE LAN Port #1
6 LAN2 10GbE LAN Port #2
7 COM1_VGA Serial Port (Top)/VGA Port (Bottom)
8 SYS_FAN5 System Fan Connector #5
9 SYS_FAN4 System Fan Connector #4
10 PMBUS PMBus Connector
11 SSATA_SGP1 SATA SGPIO Connector
12 CASE_OPEN Case Open Intrusion Alert Header
13 SL_SATA2 Slimline Connector #2 (SATA 6Gb/s Signal)
14 SL_SATA1 Slimline Connector #1 (SATA 6Gb/s Signal)
15 SSATA2 SATA 6Gb/s Connector #2
16 SSATA0 SATA 6Gb/s Connector #0
17 ATX1 2x12 Pin Main Power Connector
18 P12V_PCIE 2x3 Pin 12V Power Connector
19 BAT Battery Socket
20 CPU0_FAN2 CPU Fan Connector #2
21 CPU0_FAN1 CPU Fan Connector #1
22 P12V_AUX2 2x4 Pin 12V Power Connector
23 P12V_AUX1 2x4 Pin 12V Power Connector
24 MCIOP0_4BA MCIO Connector (PCIe Gen5)
25 MCIOP0_4DC MCIO Connector (PCIe Gen5)
26 F_USB3 Front Panel USB 3.2 Gen1 Connector
27 FP_1 Front Panel Header
28 BP_1 HDD Backplane Board Connector
29 M2_0 M.2 Slot (PCIe Gen3 x4, Support NGFF-2280/22110)
30 SYS_FAN3 System Fan Connector #3
31 SYS_FAN2 System Fan Connector #2
32 SYS_FAN1 System Fan Connector #1
33 IPMB1 IPMB Connector
34 CN_NCSI NCSI Connector
35 PCIE_1 PCIe x16 Slot #1 (Gen5 x8)
36 PCIE_2 PCIe x16 Slot #2 (Gen5 x16)
37 PCIE_3 PCIe x16 Slot #3 (Gen5 x8)
38 PCIE_4 PCIe x16 Slot #4 (Gen5 x16)
39 PCIE_5 PCIe x16 Slot #5 (Gen5 x8)
40 PCIE_6 PCIe x16 Slot #6 (Gen5 x16)
41 PCIE_7 PCIe x16 Slot #7 (Gen5 x16)

Gigabyte MS33-AR1 Specifications

General

Brand	Gigabyte
Model	MS33-AR1
Category	Motherboard
Language	English
