- 7 -
2-2 ProductSpecications
CPU
Built in with an Intel
®
Quad-Core Celeron
®
N4120 (2.6 GHz) j
Built in with an Intel
®
Dual-Core Celeron
®
N4020 (2.8 GHz) k
* Do not disassemble the onboard SoC and the heatsinks by yourself to avoid damage
to these components.
4 MB Cache
Memory 2 x DDR4 SO-DIMM sockets supporting up to 16 GB of system memory
Dual channel memory architecture
Support for DDR4 2400/2133 MHz memory modules
Support for non-ECC memory modules
Onboard
Graphics
Integrated in the SoC:
- 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.0a version and HDCP 2.2.
Audio Realtek
®
Audio CODEC
High Denition Audio
2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To
congure 7.1-channel audio, access the audio software for audio settings.
LAN Realtek
®
GbE LAN chip (1 Gbps/100 Mbps)
Expansion Slots 1 x PCI Express x1 slot, running at x1
(The PCIEX1 slot conforms to PCI Express 2.0 standard.)
1 x M.2 Socket 1 connector for the wireless communication module (CNVI)j
Storage Interface Integrated in the SoC:
- 1 x M.2 connector (Socket 3, M key, type 2280/2260/2242 SATA and
PCIe 2.0 x2 SSD support)
- 2 x SATA 6Gb/s connectors
* Refer to "2-6 Internal Connectors," for the installation notices for the M.2 and SATA
connectors.
USB Integrated in the SoC:
- 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through
the internal USB header)
- 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through
the internal USB header)
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
2 x SATA 6Gb/s connectors
1 x SoC fan header
1 x system fan header
1 x M.2 Socket 3 connector
1 x front panel header
1 x front panel audio header
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
1 x parallel port header
1 x serial port header
j Only for N4120I H.
k Only for N4020I H.
To Next Page
