English
10
1 2
• Tear the transparent lm on the thermal pad
• To paste the thermal pad on the top of M.2 SSD and aligned with the chip on the right side,
then tear the blue lm.
Installing the Thermal Pad for M.2 SSD on P55
If you want to install M.2 SSD on your P55, we strongly recommend that you should read this
instruction first in order not to installtion fail. We(GIGABYTE) won’t be responsible for any
damage from installation of SSD either by individual or vendor. So please RE-CONSIDER it
before installation, thanks!
• Open the rear cover and loose the screw
for M.2 SSD
3-1 3-2
