Gigabyte X570S AORUS ELITE AX User Manual

Expansion Slots  1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
- AMD Ryzen
™
5000 Series Processors/AMD Ryzen
™
3000 Series Processors
support PCIe 4.0 x16 mode
- AMD Ryzen
™
4000 G-Series Processors/AMD Ryzen
™
2000 Series
Processors support PCIe 3.0 x16 mode
- AMD Ryzen
™
3000 G-Series Processors/AMD Ryzen
™
2000 G-Series
Processors support PCIe 3.0 x8 mode
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
 1 x PCI Express x16 slot (PCIEX4), integrated in the Chipset:
- Supporting PCIe 4.0
(Note 2)
/3.0 x4 mode
 1 x PCI Express x16 slot (PCIEX2), integrated in the Chipset:
- Supporting PCIe 4.0
(Note 2)
/3.0 x2 mode
* The PCIEX4 slot shares bandwidth with the PCIEX2 slot. When the PCIEX2 slot is
populated, the PCIEX4 slot operates at up to x2 mode.
Multi-Graphics
Technology
(Note 3)
 Support for AMD Quad-GPU CrossFire
™
and 2-Way AMD CrossFire
™
technologies
Storage Interface  1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3,
M key, type 2260/2280/22110 SSDs:
- AMD Ryzen
™
5000 Series Processors/AMD Ryzen
™
3000 Series Processors
support SATA and PCIe 4.0 x4/x2 SSDs
- AMD Ryzen
™
4000 G-Series Processors/AMD Ryzen
™
3000 G-Series
Processors/AMD Ryzen
™
2000 Series Processors/AMD Ryzen
™
2000 G-Series
Processors support SATA and PCIe 3.0 x4/x2 SSDs
 2 x M.2 connectors (M2B_SB/M2C_SB), integrated in the Chipset, supporting
Socket 3, M key, type 2260/2280/22110 SSDs:
- Supporting SATA and PCIe 4.0
(Note 2)
/3.0 x4/x2 SSDs
 6 x SATA 6Gb/s connectors, integrated in the Chipset:
- Support for RAID 0, RAID 1, and RAID 10
* Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA
connectors.
USB  CPU:
- 4 x USB 3.2 Gen 1 ports on the back panel
 Chipset+ASMedia
®
USB 3.2 Gen 2x2 Controller:
- 1 x USB Type-C
®
port on the back panel, with USB 3.2 Gen 2x2 support
 Chipset:
- 1 x USB Type-C
®
port with USB 3.2 Gen 2 support, available through the
internal USB header
- 3 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
- 4 x USB 3.2 Gen 1 ports available through the internal USB headers
 Chipset+2 USB 2.0 Hubs:
- 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through
the internal USB headers)
(Note 2) For AMD Ryzen
™
5000 Series Processors/AMD Ryzen
™
3000 Series Processors only.
(Note 3) For AMD Ryzen
™
5000 Series Processors/AMD Ryzen
™
4000 G-Series Processors/AMD Ryzen
™
3000 Series Processors/AMD Ryzen
™
2000 Series Processors only.
- 8 -

Gigabyte X570S AORUS ELITE AX Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3, AMD Ryzen 5, AMD Ryzen 7, AMD Ryzen 9 3rd Gen, AMD Ryzen 9 5th Gen
Wi-Fi	Yes
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX200
Ethernet interface type	2.5 Gigabit Ethernet
PCI Express x16 slots	3
USB connector type	USB Type-A, USB Type-C
WiFi-AP antenna jack	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
Number of SATA III connectors	6
Cables included	SATA
Bundled software	Norton® Internet Security (OEM version), Realtek® 8125 Gaming LAN Bandwidth Control Utility
Memory channels	Dual-channel
Memory slots type	DIMM
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200, 3300, 3333, 3400, 3466, 3600, 3733, 3800, 3866, 4000, 4133, 4266, 4300, 4400, 4600, 4866, 5000, 5100, 5200, 5400 MHz
Audio chip	Realtek ALC1220-VB
Component for	PC
Motherboard chipset	AMD X570
PC health monitoring	FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 x64
RAID levels	0, 1, 10
Supported storage drive types	HDD & SSD
Number of storage drives supported	9
Supported storage drive interfaces	M.2, PCI Express 3.0, PCI Express 4.0, SATA III
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	2-Way CrossFireX, Quad-GPU CrossFireX
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	256 Mbit
Desktop Management Interface (DMI) version	2.7
Harmonized System (HS) code	84733020
Weight	1000 g

Weight and Dimensions

Depth	244 mm
Width	305 mm
Height	80 mm
