Made in Germany
© Gigahertz Solutions GmbH - 9 - May 2017
4 Switches / Push-Buttons /
Connectors
4.1 On / Off switch (“Power“)
“On” = Standard Measurement Setting
LEDs and acoustic signal remain activated for manual
measurements when you switch to “Log” until the Status-
LED is lit green, logging continues even when you switch
back to “On”.
“Log” = Logging / long term recording
All LEDs and the acoustic signal are deactivated to save bat-
tery life during data logging.
“Off” = Device is off
4.2 Field Selection for
3D Measurement
M3D = Magnetic field measurement (3D)
The isotropic point or magnetic field sensors are
below the coordinate system printed on the meter
faceplate. The dominating axis is indicated by a
red LED next to the display.
XYZ = Axis indication
Here, the NFA 1000 will show either the magnetic or the
electric field in its three individual components depending on
the field type from which the switch was set to “XYZ”,
whereas the NFA 400 will only show the individual compo-
nents of the magnetic field. Press the ‘Mode >’ button to
switch from one axis to the other. Please see chapter 4.9 for
details to this or to the automated scrolling.
