Gigatech K-350R - K-350 R KIT Parts Identification; Main Monitor; System Layout

2.K-350R KIT Parts Identification
2.1. Main Monitor
4
10 1112139
5
6
8
7
14
15
16
178mm
(7.0)
36mm
(1.42)
118mm
(4.65)
1. Micro SD card slot socket
2. 3.5" Color TFT Screen
3. Touch sensitive buttons (4 on each side, unmarked)
4. Speaker
5. In use LED
6. Monitor LED
7. Intercom LED
8. Speach open LED
9. Microphone
10. Cut-off button( )
11. Intercom button( )
12. Monitoring button( )
13. Door release button( )
14. Power switch
15. Bell Volume tuner( )
16. Speaker Volume tuner( )
K-350R Main monitor identification:
2
1
3
2
K-350R Video intercom systemIntroduction V12011-01
