GILCREST PavMaster 414 - 400 Gate Control; Operation Control Valves

14
2 3
4
5
6
7
8
9
10
11
12
1
1 1 Towarm Control / Releases and Engages Towarms
2* 1 Gate Control / Opens and Closes Hopper Gates
3 1 Wing Control / Extends and Retracts Wings
4 1 Extension Control / Extends and Retracts Screed Extensions LS
5 1 Screed Depth Control / Raises and Lowers paving surface LS
6 1 400 Gate Control LS / Sets Gates to be used separate or together
7 1 400 Gate Control RS / Sets Gates to be used separate or together
8 1 Screed Lift Control / Raises and Lowers Screed
9 1 Gate Control / Opens and Closes Hopper Gate
10 1 Wing Control / Extends and Retracts Wings
11 1 Extension Control / Extends and Retracts Screed Extensions RS
12 1 Screed Depth Control / Raises and Lowers paving surface RS
* When Gate Control Knobs are in the out position the gates operate separately
When Gate Control Knobs are in the in position the gates operate together
Operation Control Valves
Item . Qty Description Pg.#
