1  INTRODUCTION
PIPETMAN
®
Fixed volume
pipettes are available in 14
dierent models. Together,
they cover a range of vol-
umes from 2 to 5000 µL.
The pipetting mechanism
incorporates a highly pol-
ished stainless steel piston,
a seal, and an O-ring. The
mechanism requires no
routine lubrication.
Tip-ejector and disposable
tips mean no need to handle
tips, protecting the user
from contamination.
The tip-holder, the connect-
ing nut and the tip-ejector
are autoclavable for 20
minutes at 121°C and 0.1
MPa pressure.
CONTENTS page
1  INTRODUCTION 2
2  SPECIFICATIONS 3
3  OPERATION 4
4  USER ADJUSTMENT 5
5  PRERINSING 6
6  PIPETMAN DIAMOND
®
TIPS 7
7  RECOMMENDATIONS 9
8  TROUBLESHOOTING 10
9  SPARE PARTS 11
EC DECLARATION OF CONFORMITY 13
Push button
Tip-ejector
button
Body or
handle
Connecting
nut
Diamond tip
Tip-ejector
Tip-holder
Figure 1
