Instructions For Use

The operating and maintenance instructions found in this manual should be followed to ensure

years of reliable service.

Please read these instructions carefully before using the Sigma and keep them in a safe

place for future or use reference.

Intended Use

Sigma Otoscopes and associated accessories are intended for the examination of ear, the

external auditory canal and the eardrum.

This instrument has an optical magnifying lens and battery-powered illumination handle, and

recommendedforusebymedicallyqualiedpersonneltoassessthehealthofearthrough

transmitting light into the ear canal.

This device is intended for transit treatment and examination.

Setting Up the Product

Head & Handle Attachment

To setup the Sigma Otoscope, align the otoscope thread with handle and rotate the head

clockwiseuntilheadandhandlermlyjoined.(Fig-2,A )

Sigma Battery Handle

The Sigma battery handle should only be used as a power source for Sigma instruments.

Grip the handle attached to Otoscope head. To turn ON the light, slide the switch with thumb

towards the bottom of the handle.

To turn OFF the light, slide the switch with thumb towards the top of the handle. (Fig-2, B)

Insert Batteries

Arrange twoAA/LR6size good quality alkaline batteriesforpower. Rotateendcap

counterclockwise to open the handle end cap. Insert two batteries into handle with positive

(+) terminal towards the head and close the cap by rotating clockwise (Fig-2, C).

Note: Batteries are not included in sets.

The Otoscope is intended for transit treatment and the handle may gets warm by longer use.

So let it be cool down before next application.

Aharmlessmaxtemperatureof60°Cwillnotbeexceeded.

Sigma xenon otoscope model

Bulb Replacement

Rotate otoscope head counterclockwise to detach from handle.

Pull down the bulb and insert new bulb into socket and rotate the head clockwise until head

andhandlermlyjoined(Fig-3).

Before replacing the bulb read below instruction carefully.

Let the device cool down before changing the bulb.

Verify the bulb voltage / specication before changing.
