6
Wall
Installing the bracket
Use the installation template(page 15) to mark the location of the 4 holes.
First recommend a 7/16" drill, if not available you can choose a 3/8" drill, then drill
1-31/32''/4.98cm deep holes.
Hammer wall anchors into the 4 holes.
Hold the bracket in place, then put the screws in, and use a socket set or a Phillips
screwdriver to tighten.
1.
2.
3.
4.
Tips: Depth is important. Mark a 1-31/32''/4.98cm depth with tape around the drill bit. If the drilled hole is
too deep and the wall anchor rotates, use a matchstick or a similar tool to tighten the hole.
