6
Wall / Post
Installing the bracket
Use the installation template(page 14) to mark the location of the 4 holes.
Use a 1/2" drill bit to drill 1.96in./4.98cm. deep holes.
Remove the nuts and washers, hammer wall anchors into the 4 holes.
Hang the bracket on the anchors, put on the washers and screw on the nuts, then use
a socket set or a Phillips screwdriver to tighten.
1.
2.
3.
4.
Tips: Depth is important. Mark a 1.96in./4.98cm. depth with tape around the drill bit. If the drilled hole is
too deep and the wall anchor rotates, use a matchstick or a similar tool to tighten the hole.
