10 11
Connect the lance to pressure gun. See figure 4.
Push the trigger lock button, ensure the trigger in the “OFF” position. See figure 5 and 6.
Check the water inlet adapter to make sure it is free of blockage.
Fixing the water inlet adapter to the water inlet of unit. See figure 7. Connect your
water supply hose to the water inlet adapter.
2.
3.
4.
5.
Figure 4: Lance connect
Figure 5&6: Trigger lock
Figure 7: Water inlet adapter connect
Fixing the matching end of the hose firmly into the gun handle. See figure 2 and 3.
Tighten the connector by hand only. Loosen the high pressure hose to avoid twist.
1.
Way to Use
Figure 1: Wall base dimensions
Figure 2&3: Pressure hose connect
