This document is a user manual for the Giraffe Tools Retractable Air Hose Reel, Model TA10B. It provides comprehensive information regarding the product's function, technical specifications, usage, maintenance, and warranty.

Function Description

The Giraffe Tools Ret retractable Air Hose Reel is designed to store and manage an air hose, featuring an auto-retractable mechanism for ease of use. It can be mounted on a wall or ceiling and is equipped with a single guide arm that can be repositioned within 225° to optimize its function and hose direction. The reel's primary purpose is to provide a convenient and organized solution for air hose storage and deployment, preventing kinks and tangles while ensuring easy access to compressed air.

Important Technical Specifications

The manual provides detailed technical specifications for the Steel Air Hose Reel:

Type: Steel Air Hose Reel
Length: 25 feet
Inner Diameter: 3/8 inch
Connect Type: 1/4 inch NPT
Hose Material: Hybrid
Max. Working Pressure: 300 PSI
Mount Type: Wall, Ceiling, Floor

Dimensions:

Overall Width: 11.024 inches
Overall Height: 12.520 inches
Side Profile Depth (excluding mounting bracket): 4.724 inches
Mounting Bracket Dimensions:
- Height: 5.709 inches
- Width: 7.087 inches
- Thickness: 0.512 inches
- Hole Spacing (vertical): 2.283 inches
- Hole Spacing (horizontal): 2.3 inches (for the installation template)

Installation Requirements:

The reel must be installed on a solid surface capable of withstanding 20kg of force, accounting for the weight of the filled reel and the pulling force during use.
The installation requires four expansion bolts (Ф12*70, included).
Tools required for installation include an electric drill (9/16"), a hammer, and a socket set or Phillips screwdriver.

Usage Features

The retractable air hose reel offers several user-friendly features:

Lock/Extend the Hose: The reel incorporates serial locking and non-locking areas within its steel body. Users will hear an audible "click" when the hose passes through a locking area. To lock the hose, pull it out and stop when a "click" sound is heard.

Retract/Shorten the Hose: To unlock the hose, give it a small tug until it reaches a non-locking area (where no click is heard), initiating retraction. To shorten the hose to a specific length, start retraction and stop when a "click" is heard at the desired point.

Important Usage Tips:

Hose locking is only possible during the pulling-out process, not during retraction.
Always retract the hose gently. Failure to do so with caution may damage the hose reel.
Walking backward at a steady speed during retraction allows the self-segmenting mechanism to neatly insert and weave the hose into the reel, preventing kinks and tangles.
Always retract the hose after each use.
A "STOP" indication sticker is placed 3.28 feet before the maximum hose length. Users are advised not to pull the hose past this point to avoid damaging the retraction mechanism.

Guide Arm Repositioning: The guide arm can be rotated to a desired position within 225°. To reposition, pull out and lock the hose, remove the nut and washer on the guide arm base, rotate the arm, and then re-tighten the washer and nut.

Maintenance Features

The manual outlines important air tool precautions and general care and maintenance procedures to ensure the longevity and safe operation of the hose reel.

Air Tool Precautions:

Inspect Air Hose: Before each use, inspect the air hose for cracks, fraying, or other faults. Discontinue use if damage or hissing is detected and replace the defective component/air hose.
Protect Air Hose: Prevent people, mobile equipment, or vehicles from passing over unprotected air hoses. Position the hose away from high-traffic areas, or use reinforced conduits or planks to create an enclosed area.
Prevent Damage:
- Never carry the tool by the air hose.
- Keep the air hose away from heat, oil, sharp edges, or moving parts.
Check Pressure Rating: Verify the maximum pressure rating for air tools and accessories. Ensure the compressor outlet pressure is regulated to never exceed the tool's maximum pressure rating.

Care & Maintenance:

CAUTION: Always release air pressure from the hose system before servicing the reel.

Maintain with Care: Proper maintenance ensures efficiency, easier control, and fewer problems.
Inspect Components: Regularly inspect the reel, hose, and accessories for damage or excessive wear.
Repair/Replace: Have damaged or worn components repaired or replaced by an authorized technician. Use only identical replacement parts.
Accessories: Only use accessories intended for use with this tool.
Labels/Name Plates: Maintain the tool's labels and name plates, as they carry important information. Contact Giraffe Tools for replacements if unreadable or missing.

WARNING: Only qualified service personnel should repair the tool, as improper repairs can pose hazards to the user.

Cleaning: Wipe the surface of the reel with a clean, moist cloth. Do not use solvents for cleaning.

Safety: The manual emphasizes reading and understanding all instructions before use, following basic precautions to reduce the risk of personal injury and equipment damage. It defines hazard notices (WARNING, CAUTION, NOTICE) and provides guidelines for work area safety and personal safety, including wearing personal protective equipment (impact safety goggles, gloves, protective clothing, non-skid footwear). Specific safety precautions include using the correct tool for the job, ensuring proper installation, removing system pressure immediately if a leak occurs or the reel ceases to function, and controlling the hose slowly during retraction.
