c. Remove the 4 cross head screws holding the module together. Remove the base plate

and silicone insert. See Fig.3.

Fig.3

d. Turn the base plate over (Magnet down). Then place the motion sensor on top of it so

that the magnet is aligned with the reed switch. See fig.4.

If this is not done the

default program cannot be changed.

Fig.4

Base plate

Magnet

Silicone Insert

Reed Switch

LED

Sensitivity Dial

Program Button
