Page 11 of 11
Note; when carrying out this part of the procedure each step must be
executed within 10 seconds of the previous one or the module will revert to
factory settings. It is highly recommended that you read and understand the
following sequence before attempting to execute it.
a.
Set the Motion sensor Adjustment Dial to level 5. (See Fig.4)
b.
To initiate the programming sequence, power to the motor controller must be
disconnected for at least 10 seconds then reconnected.
c.
Connect the GC779G Motion sensor to a 12volt DC circuit. At this point the
Purple LED will illuminate and then begin to blink. If it does not, the module is
not receiving the correct power. Ensure that the magnet and reed switch are
aligned and verify the electrical connection before proceeding.
d.
Press and hold the MIDDLE and RIGHT buttons on the GC274B (Fig 2) for
about 3 seconds until the Green LED starts to flash.
e.
Press the Stop button on the Motor controller (see fig.4). The green LED will
illuminate continuously.
f.
Press the programming button on the GC779G Motion sensor (See Fig.4). Both
the Purple LED on the Motion sensor and the green LED on the Motor controller
will flash once and extinguish. This completes the programming sequence.
g.
Ensure that the code was accepted by pressing the Program button on the
GC779G Motion sensor again. The Awning should retract.
h.
If the Awning does not retract, repeat steps a. to f.
i.
Set the Adjustment Dial to the desired sensitivity level 1 to 5. Never set higher
than 5. (The factory setting is 3).
Once programming is complete, reassemble the motion sensor module and
mount on the awning lead rail.
For queries or assistance with programming any of your G-Link devices
please call Girard Systems TOLL FREE on 800–382–8442 between 7:30am
and 3:30pm P.S.T.
