7.3.7. INFO A6 Mode
The A6 Info mode makes it possible to interact with the A6(I/O2) board, and is activated from the menu: System
Tools - Configuring operating parameters and programming - Advanced programming options. The A6 Info
mode makes it possible to:
Info A6 mode not used.
<<< Option programmed by default
Transfer the linen load value.
Default value: Nominal washing machine load.
Enter a decimal numerical value (0-255) whose conversion to a binary base will activate the
corresponding output on the A6(I/O2) board.
Default value: 0.
For further information see Section 7.5 and the examples of use in the appendices at the end of this
manual.
7.3.8. Information time in Info A6 mode
After choosing any of the A6 info options, the user should choose the length of time that this feature will be
enabled on the A6(I/O2) board.
Programmable time range: 1 – 255 seconds.
Value programmed by default: 5 sec.
7.3.9. Rotation. Start – Stop Sequence
This function allows selecting distinct start-and-stop drum rotation sequences.
The programmed sequence is maintained during the entire phase.
There are five pre-programmed rotation sequences that are modifiable in the CONFIGURATION of the washing
machine.
Value ON: drum rotation time in seconds
Value OFF: drum rotation time in seconds
Programmable reverse sequences
Default values
No rotation
There is no drum movement
Reverse sequence 1
WR1
ON: 5sec. – OFF: 55sec.
Reverse sequence 2
WR2
ON:5sec. – OFF: 10sec.
Reverse sequence 3
WR3
ON:5sec. – OFF: 25sec.
Reverse sequence 4
WR4
ON: 15sec. – OFF: 15sec.
Reverse sequence 5
<<< Option programmed by default
WR5
ON: 25sec. – OFF: 5sec.
