GIRBAU LOGI CONTROL Operation Instructions

Cod. 429266
Rev. 01/0206
Operation
13
USA / CANADA application
Pr - 1. EXTRA HEAVY SOIL - WHITE  27 MIN. Pr - 2. HEAVY SOIL - WHITE  22 MIN.
Ph L F d r rt cd rh E Et Ph L F d r rt cd rh E Et
1
1 113 2 1 9 0 - - - 1 - - -
1
1 104 2 1 6 0 - - - 1 - - -
2
2 32 3 1 2 - - - - - - 3 2
2
2 32 3 1 3 - - - - - - 3 2
3
2 - - - - - - 1 1 - - - - - - 1 - - -
3
2 32 4 1 2 - - - 0 6 5
4
2 32 4 1 2 - - - 0 6 5
Pr - 3. MEDIUM SOIL - WHITE  22 MIN.
Pr - 4. L
IGHT SOIL - WHITE  20 MIN.
Ph L F d r rt cd rh E Et Ph L F d r rt cd rh E Et
1
1 86 2 1 6 0 - - - 1 - - -
1
1 68 2 1 4 1 - - - 1 - - -
2
2 32 3 1 3 - - - - - - 3 2
2
2 32 3 1 3 - - - - - - 3 2
3
2 32 4 1 2 - - - 0 6 5
3
2 32 4 1 2 - - - 0 6 5
Pr - 5. HEAVY SOIL - COLOR  22 MIN. Pr - 6. MEDIUM SOIL - COLOR  21 MIN.
Ph L F d r rt cd rh E Et Ph L F d r rt cd rh E Et
1
1 104 2 1 8 0 - - - 1 - - -
1
1 104 2 1 6 0 - - - 1 - - -
2
2 32 0 2 1 - - - - - - 3 2
2
2 32 0 2 1 - - - - - - 3 2
3
2 32 4 2 2 - - - 0 6 5
3
2 32 4 2 3 - - - 0 6 5
Pr - 7. SYNTHETICS  18 MIN. Pr - 8. WOOL & DELICATE  17 MIN.
Ph L F d r rt cd rh E Et Ph L F d r rt cd rh E Et
1
1 86 2 2 4 0 - - - 1 - - -
1
2 68 2 2 6 - - - - - - 1 - - -
2
2 32 0 2 1 - - - - - - 3 2
2
2 32 0 3 1 1 - - - 1 - - -
3
2 32 4 2 2 - - - 0 6 5
3
2 32 4 3 2 - - - 0 4 3
The parameters that appear on the chart can be modified: See the Advanced Operation Instructions LOGI
CONTROL at the manufacturer’s website:
www.girbau.com
(USA/CANADA www.cont-girbau.com).
