Indicator LED
Connection method
Wi-Fi
USB
Charge
LED
Blinking blue
Blue/green flashing
Blinking green
Green light
Red/blue flashing
Blinking red
Red light
Red off
Blue light
Status
At boot
When booting up /
Waiting for Wi-Fi connection
Connecting to Wi-Fi
Upon Wi-Fi connection
Low battery
At power off
Charging
Fully charged
When the program is connected
Wi-Fi mode power button
UP button: LED Brightness button (0~3step)
DOWN button: Preview Rotation Button(90degrees)
Capture button
Long press: Start / stop movie recording
Short press: Take a picture
+DC 5V Input terminal
USB Input terminal
C1. Name of each part
6
